Parameter

Specification

Vehicle Model

SHACMAN F3000 8×4 Dump Truck

Vehicle Type

Dump Truck / Tipper Truck

Drive Type

8×4

Cabin

F3000 Flat Roof / High Roof Cabin

Driving Type

Left-hand Drive / Right-hand Drive

Seat Configuration

2 Seats + 1 Sleeper

Cabin Equipment

Air Conditioner, Air Suspension Seat, Electric Window, Central Lock

Engine Brand

WEICHAI / CUMMINS

Engine Model

WP12.430E201 / WP13 Series

Horsepower

380 HP / 400 HP / 430 HP

Emission Standard

Euro II / Euro III / Euro V

Displacement

11.596 L

Maximum Torque

2060 N·m

Transmission Brand

FAST

Transmission Model

12JSD200T

Gearbox

12 Forward & 2 Reverse

Clutch

430 mm Diaphragm Clutch

Front Axle

9.5T MAN Axle ×2

Rear Axle

16T MAN Double Reduction Axle ×2

Axle Ratio

5.262 / 5.92 Optional

Steering System

ZF Hydraulic Steering

Brake System

Dual Circuit Air Brake

Parking Brake

Spring Energy Brake

ABS

Optional

Suspension

Heavy-duty Multi-leaf Spring

Fuel Tank Capacity

400 L

Tire Specification

12.00R20 / 315/80R22.5

Number Of Tires

12 + 1 Spare Tire

Wheelbase

1800 + 3575 + 1400 mm

Overall Dimension

10500 × 2550 × 3450 mm

Dump Body Length

7600 mm

Dump Body Width

2300 mm

Dump Body Height

1500 mm

Cargo Body Material

High-strength Steel

Lifting System

Front Hydraulic Lifting

Cargo Volume

26–35 m³

GVW

50000 kg

Curb Weight

15500 kg

Payload Capacity

30–40 Tons

Maximum Speed

80 km/h

Ground Clearance

314 mm

Application

Mining / Construction / Quarry / Earthwork Transport

Optional Configuration

Customized Configuration Supported
